Yamaha AX-390 – Stereo Integrated Amplifier
€ 200,00
Yamaha AX-390 – Stereo Integrated Amplifier
Specifications
Power output: 60 watts per channel into 8Ω (stereo)
Frequency response: 20Hz to 20kHz
Total harmonic distortion: 0.04%
Damping factor: 100
Input sensitivity: 2.5mV (MM), 150mV (line)
Signal to noise ratio: 82dB (MM), 102dB (line)
Channel separation: 65dB (MM), 60dB (line)
Output: 150mV (line)
Dimensions: 435 x 146 x 309mm
Weight: 7.3kg
Accessories: remote control
*This is a refurbished product in full working condition, sold with two month warranty
In stock
Description
Yamaha AX-390 – Stereo Integrated Amplifier
General
Manufacturer: Yamaha
Model: AX-390
Type: Integrated amplifier
Years of manufacture: 1995 – 1997
Made in: Malaysia
Colours: Black, Titanium
Remote control: yes
Power consumption: 150 W max.
Dimensions: 435 x 146 x 309 mm (WxHxD)
Weight: 7.3 kg
Original price approx.: 400 DM, 211 € (converted)
Connections
Number of inputs:
Phono MM 2.5 mV / 47 kOhm.
CD, Tuner, AUX, 2 x Tape 150 mV / 47 kOhm
Number of outputs:
2 x loudspeaker
2 x Rec-Out 150 mV / 600 Ohm
Headphones 0.42 V / 390 Ohm
Technical Data
Continuous power (at distortion factor)
8 Ohm: 2 x 60 Watt at 0.04
4 Ohm: 2 x 90 Watt (DIN)
Dynamic power
8 Ohm: 2 x 80 Watt
4 Ohm: 2 x 115 Watt
Total harmonic distortion: 0.02 %
Attenuation factor: 100
Frequency response: 10-40,000 Hz
Signal-to-noise ratio: 108 dB
Stereo channel separation: 60 dB
Tone control:
Bass: ±10 dB at 20 Hz
Treble: ±10 dB at 20,000 Hz
Loudness: adjustable
High Filter: no
Low Filter (Subsonic): no
Mute: no
Direct/Line-Straight: CD-Direct
